键合铜丝Copper bonding wire

HC-1

普通硬度

Hard

电热性能优良，金属间化合物生产速度慢，低成本
Excellent electric and thermal performance,Lesser growth of Intermetallic compound,Very low cost

分立器件（TO，SOT，SOD）；IC （DIP，SIP，SOP，QFP）
TR(TO,SOT,SOD),IC(DIP,SIP,SOP,QFP)

HC-2

软铜

Soft

HC-3

超软铜

Super soft

钯铜丝

Pd coated copper wire

HCP-1

普通硬度

Hard

表面镀钯，良好抗氧化性，电热性能优良，金属间化合物生长速度慢，低成本
Good oxidation resistance,Excellent electric and thermal performance,Lesser growth of Intermetallic compound Low cost

LED封装
IC封装（QFN，QFP，BGA，CSP，RGB）LED,IC（QFN，QFP，BGA，CSP，RGB）

HCP-2

软铜

Soft

HCP-3

超软铜

Super soft

金钯铜丝

Pd-Au coated copper wire

HCA-1

软铜

Soft

表面镀金钯，高可靠的第二点接合性，良好抗氧化性
Good oxidation resistance,Excellent 2st bonding reliability

IC封装（QFN，QFP，BGA，CSP
IC (QFN,QFP,BGA,CSP)

HCA-2

超软铜

Super soft

mm

mil

HC-1/HCP-1

HC-2/HCP-2

HC-3/HCP-3

HC-1/HCP-1

HC-2/HCP-2

HC-3/HCP-3

0.013

0.52

1.0

1.5

1.0

4.0-10.0

4.0-10.0

4.0-10.0

0.015

0.60

1.5

2.0

1.5

5.0-11.0

5.0-11.0

5.0-11.0

0.016

0.64

2.0

2.0

2.0

6.0-12.0

6.0-12.0

6.0-12.0

0.017

0.68

2.5

2.5

2.5

7.0-13.0

7.0-13.0

7.0-13.0

0.018

0.70

3.5

3.0

3.0

8.0-14.0

8.0-14.0

9.0-15.0

0.019

0.75

4.0

3.5

3.5

8.0-14.0

8.0-14.0

9.0-15.0

0.020

0.80

4.5

4.0

4.0

8.0-15.0

9.0-15.0

10.0-16.0

0.021

0.84

5.0

4.5

4.0

8.0-15.0

9.0-16.0

10.0-17.0

0.022

0.87

5.5

5.0

4.5

8.0-15.0

9.0-16.0

10.0-17.0

0.023

0.90

6.5

6.0

5.5

8.0-16.0

9.0-17.0

10.0-18.0

0.024

0.95

8.0

7.5

7.0

8.0-17.0

9.0-18.0

10.0-19.0

0.025

1.00

9.0

8.5

8.0

8.0-17.0

9.0-18.0

10.0-19.0

0.028

1.12

11.0

10.0

10.0

8.0-18.0

9.0-19.0

10.0-20.0

0.030

1.20

11.0

10.0

10.0

9.0-19.0

10.0-20.0

11.0-21.0

0.032

1.25

11.0

10.0

10.0

9.0-19.0

10.0-20.0

11.0-21.0

0.033

1.30

11.0

10.0

10.0

9.0-19.0

10.0-20.0

11.0-21.0

0.035

1.40

11.0

10.0

10.0

10.0-20.0

11.0-21.0

12.0-22.0

0.038

1.50

16.0

15.0

14.0

10.0-20.0

11.0-22.0

12.0-22.0

0.040

1.60

16.0

15.0

14.0

10.0-20.0

11.0-22.0

13.0-23.0

0.042

1.65

22.0

20.0

18.0

11.0-21.0

12.0-24.0

14.0-24.0

0.043

1.70

22.0

20.0

18.0

11.0-21.0

12.0-24.0

14.0-24.0

0.044

1.76

24.0

22.0

20.0

11.0-21.0

12.0-24.0

14.0-24.0

0.045

1.80

24.0

22.0

20.0

11.0-21.0

12.0-25.0

14.0-24.0

0.050

2.00

30.0

28.0

26.0

12.0-22.0

13.0-25.0

15.0-25.0
